DORMA TS 77 Hold open Rp.403.920,-
DATA & FEATURE
Closing force Size 2, 3, 4
Standard doors 850 mm up to 950 mm -1100 mm
External doors, opening outwards Non-handed
Arm assembly type Standard,Slide channel
Closing force variable at adjustment screw
Closing speed variable by valve adjustment Backcheck
Delayed action,Hold-open "
Weight in kg 1.7
Dimensions in mm Length 180
Overall depth 265
Height 43Option
Brosure
1)
For applications involving particularly heavy doors and doors which
have to close against wind resistance, we recommend the DORMA TS 83.
___________________________________________________________________________________
Dorma TS 68 Rp.302.904,-
Dorma TS 68 Hold open Rp.653.400,-
DATA & FEATURE
Closing force Size 2, 3, 4
Standard doors 850 mm up to 950 -1100 mm
External doors, opening outwards Non-handed
Arm assembly type Standard,Slide channel
Closing force variable at adjustment screw
Closing speed variable by valve adjustment Backcheck
Delayed action,Hold-open "
Weight in kg 1.7
Dimensions in mm Length 180
Overall depth 265
Height 43Option
Brosure
1)
For applications involving particularly heavy doors and doors which
have to close against wind resistance, we recommend the DORMA TS 83.
____________________________________________________________________________________
Dorma TS 71 Rp.801.900,-
Dorma TS 71 Hold open Rp.1.128.600,-
DATA & FEATURE
Door Closer Closing force Size EN adjustable 2– 4
Standard doors 1100 mm External doors,
outwards Fire doors 1100 mm Same design for DIN-L
and DIN-R Arm Standard Flat form Slide channel
Closing force adjustable by meansof setting screw and power shoe
Closing speed adjustable by meansof valve
Adjustable latching action By arm By valve
Backcheck Delayed action
Hold-open
Weight in kg 1.8
Dimensions in mm Length 233
Depth 42.5
Height 60
Option
Brosure
For high and heavy doors, external doors, and for doors required to close against high wind pressure,
we recommend DORMA TS 83.
____________________________________________________________________________
DORMA TS 72 Rp.
Rack-and-pinion door closer with scissor arm
The DORMA TS 72 is the ideal multi-purpose door closer for
all standard door designs and constructions. Without a backplate, it is
particularly easy and quick to fix. The spring strength can be
individually adapted to the door size by means of an adjusting screw.
Certified to ISO 9001.
Brosure
_______________________________________________________________________________________
Dorma TS 73 Rp.Call
Door Closer Closing force Size EN adjustable 2– 4
Standard doors 1100 mm External doors,
opening outwards Fire doors 1100 mm Same design for DIN-L
and DIN-R Arm Standard Flat form Slide channel
Closing force adjustable by meansof setting screw and power shoe
Closing speed adjustable by meansof valve
Adjustable latching action By arm By valve
Backcheck Delayed action
Hold-open
Weight in kg 1.8
Dimensions in mm Length 233
Depth 42.5
Height 60
Option
Brosure
For high and heavy doors, external doors, and for doors required to close against high wind pressure,
we recommend DORMA TS 83.
___________________________________________________________________________________
Dorma TS73V Rp.1.199.880,-
Dorma TS73V Hold Open Rp.1.900.900,-
DATA & FEATURE
Door Closer Closing force Size EN adjustable 2– 4
Standard doors 1100 mm External doors,
opening outwards Fire doors 1100 mm Same design for DIN-L
and DIN-R Arm Standard Flat form Slide channel
Closing force adjustable by meansof setting screw and power shoe
Closing speed adjustable by meansof valve
Adjustable latching action By arm By valve
Backcheck Delayed action
Hold-open
Weight in kg 1.8
Dimensions in mm Length 233
Depth 42.5
Height 60
Option
Brosure
For high and heavy doors, external doors, and for doors required to close against high wind pressure,
we recommend DORMA TS 83.
____________________________________________________________________________
Dorma TS 90,standard Rp.1.185.030,-
Dorma TS 90,Hold Open Rp.1.580.404,-
DATA & FEATURE
Closing force Size EN 3/4
Standard doors ≤ 1100 mm External doors,
outward opening Fire and smoke check doors Non-handed Arm assembly Slide channel
Two independent valves for closing speed adjustment2
Cushioned limit stay (mechanical) Delayed action Hold-open
Weight in kg 1.7
Dimensions in mm Length 246
Overall depth 46 Height 57
Door closer compliant with EN 1154
mark for construction products
option
Brosure
1) In the case of particularly heavy doors and doors that, have to close against wind pressure, we recommend the
DORMA TS 93.
_____________________________________________________________________________
Dorma TS 8300 Rp.1.900.800,-
Dorma TS 8300 Hold Open Rp.2.255.700,-
Brosure
DATA & FUTURE
Variable Spring EN EN closing force strength 3 – 6, 7
Standard doors 1400 mm – 1600 mm
External doors,1400 mm – outward opening 1600 mm
Fire and smoke 1400 mm check doors 1600 mm
Non-handed 2 2
Arm assembly type Standard
Flat-form,Slide channel
Closing force
variable by means of adjustment screw
Closing speed 180° - 70° ,70° - 15°
adjustable at 3 separate valves 15° - 0°
Closing speed variable by means of valve adjustment Adjustable latching action by arm
Backcheck self-regulating adjustable at valve Delayed action variable at valve
Hold-open "
Weight in kg 1.7 3.3
Dimensions in mm Length 245 293
Overall depth 46 47.5
Height 60 60
Door closer tested to EN 1154 mark for construction products
Approved to AS1905 Part1 Fire Resistant Doors
option
1) For applications involving particularly heavy or wide doors, and
doors which have to close against wind resistance, the next
highest closer size or a higher spring strength should be applied.
____________________________________________________
Dorma TS 93 FIRE Rp.2.400.300,-
DATA & FEATURE
Variable closing force Spring strength 1–5 5–7 Standard doors 1250 mm –1600 mm
External doors,1250 mm – outward opening 1600 mm
For fire and 1250 mm smoke check doors 1600 mm
Non-handed Arm assembly type Standard Slide channel
Closing force variable by means of adjustment screw
Closing speed adjustable by valve Latching speed at arm
adjustable at valve Backcheck (BC/ÖD) adjustable at valve
Delayed action (DC/SV)
adjustable at valve Hold-open
Weight in kg 3,5 5,2
Dimensions in mm Length (L) 275 285
Overall depth (B) 253 262
Height (H) 260 271
Door closer tested to EN 1154
Hold-open devices tested to EN 1155
Door co-ordinators tested to EN 1158
mark for building products
Approved to AS1905 Part1 Fire Resistant Doors
Brosure
_____________________________________________________________________________
CATATAN :
SILAHKAN HUBUNGI KAMI UNTUK TYPE YG TIDAK TERCANTUM PADA BLOGGER KAMI
1. DORMA ITS 96
2. DORMA RTS 85
3. DORMA 93 EMF
4. DLL
